BÜCHI

Parallel Chemistry

PolyBLOCK Plate The PolyBLOCK Plate is designed for use with all standard SBS footprint plates and features two independently controlled heated (up to 190 OC) positions with magnetic stirring. HEL has extensively checked the magnetic stirring on this system and it provides effective magnetic agitation in all positions on a standard plate. Magnetic agitation is superior to mixing achieved by vortexing and avoids the problems associated with the strong magnetic fields used for tumble stirring.	PolyBLOCK A compact, flexible, economic reaction block, with 4 or 8 reaction zones - each independently controlled and monitored. Vessels range from 1 to 500ml. Stirring & Temperature can be monitored and controlled in real-time using HEL's WinISO control software.	AutoMATE Chemistry platforms with independently controlled zones, offering both high and low pressure solutions. Options of 2, 4, 6 or 8 zones available, with the facility to mix and match different reactors/vials with low & high pressure. An endlessly flexible platform supporting activities from screening to process optimisation and scale-up.
AutoLAB digi-plate Using familiar stirred hotplate with touchscreen controls and a wide choice of reaction vessels, busy chemists can rely on the AutoLAB digi-plate for reproducible results.	HP ChemSCAN This is a highly automated platform that allows parallel screening of catalytic reactions. Each sample can be at a different temperature and pressure and the reaction process (in term of gas consumption) is tracked in real time which provides information on reaction kinetics. Pressure of 200bar and temperature up to 250C is possible.	CrystalSCAN The CrystalSCAN is a versatile automated platform for determining Solubility and Meta-Stable Zone Width (MSZW), in multiple, parallel samples. With precise temperature-control and integrated dilution pumps, the system allows for the investigation over a wide concentration and temperature range.
CATalyst Screening Several products (CAT 7, 18, 24, 96, polyCAT) are offered under manual control, with samples all at the same temperature and pressure. The PolyCAT allows some degree of automation and ability to vary temperature and pressure among samples. The simplicity of design enables competitive pricing.	HP PolyBLOCK The High Pressure PolyBLOCK is a 4 or 8 zone reactor block, with independent Pressure and Temperature monitoring & control. The system has been designed for both Process Development and High-Pressure/High-Throughput work. A range of parallel reactors are available from 1 to 400mL rated to 100Bar as standard.	HP AutoMATE With volumes of 16ml to 400ml and pressure of 200bar, this is the world leader in high pressure parallel chemistry. Ease of use, compact design, with a wide range of features including sampling under pressure.
LP ChemSCAN The LP ChemSCAN (LPCS) combines intelligent robotic liquid handling with the versatility of a multipot reaction block. The block provides independent heating and stirring on 4 or 8 zones and the robot extends this functionality - allowing for literally hundreds of manual experiments to be condensed into a single expt on a single platform.	ASu The ASu is a 6-position autosampling unit. Operated either by keypad or via PC control - the system is ideal for safe and easy automated removal of multiple liquid or slurry samples, from any size reactor.
